2013 GT Karakoram Hans Rey
2013 GT Karakoram Hans Rey is a 29er mountain bike built around a hydroformed Speed Metal aluminum frame with Shimano Alivio drivetrain and hydraulic disc brakes.
Description
This bike respects your skills. Steep descents, rocky climbs, and jeering friends can make any ride feel like a challenge, both to your skills and to your ego. Fortunately you perform under pressure, and you’re on a Karakoram, which is just as relaxed in a crux as you are. Responsive, indestructible, and smooth on the trail, it’s all the bike you need to show your buddies the skills it takes to be a bad ass.
Technical specification
Geometry
- Sizes
- S, M, L, XL
Frame & Fork
- Frame
- NEW 29" Hydroformed & Butted Speed Metal™ Aluminum (TT/DT) Frame, w/ Triple Triangle™, Replaceable Derailleur Hanger, Disc Brake Mounts, and Zerostack 1 1/8" Head Tube
- Fork
- Rock Shox XC28 TK Mg w/100mm Travel, 29", Hydraulically Damped, Magnesium Lowers, 28mm Chrome Steel Uppers, Forged Crown, Post Mount Disc Brake, Turn Key Lock Out, Rebound Adjust, QR
Drivetrain
- Crankset
- Shimano Alivio FC-M430, 44/32/22T
- Bottom bracket
- Tange Sealed
- Chain
- HG53
- Freewheel
- Shimano CS-HG30-9, 11-34T, 9 Speed
- Shifters
- Shimano Alivio, Sl-M430, Rapid Fire
- Pedals
- GT Slim Line Flat Pedal, Cast Alloy
- Front derailleur
- Shimano Acera FD-M390
- Rear derailleur
- Shimano Deore Shadow, RD-M592
Wheels
- Rims
- Alex TD19, Double Wall, 32H
- Tires
- Kenda H-Factor, 60TPI, 29X2.20"
- Spokes
- 14G Stainless
- Hubs
- All Terra Alloy Disc, W/ Quick Release
- Rear hub
- All Terra Alloy Cassette Disc, W/ Quick Release
Cockpit & contact
- Handlebar
- crankbrothers Cobalt 1 Riser, 700mm Width, 15mm Rise, 31.8mm Clamp
- Stem
- crankbrothers Iodine 2, 1 1/8" Threadless, 6° Rise, 31.8mm Clamp
- Grips
- GT Wings w/ Waffle Lock On
- Headset
- FSA No.10 1 1/8" Threadless, Zerostack
- Saddle
- All Terra Tacoma
- Seat post
- crankbrothers Cobalt 1, 30.9mm
- Seatpost clamp
- All Terra Alloy QR
- Colour
- White
Brakes
- Brakes
- Shimano BR-M395, Hydraulic Disc, W/ 160mm Rotor
- Brake levers
- Shimano BL-M395 Hydraulic
